Feature Introduction:
THE K11™ PEEK GF10 is a glass fiber-reinforced PEEK material with high strength and rigidity, and resistance to high temperatures.Instead of metal parts in many applications, printed parts are lightweight and strong, which functions are similar to PEEK K10CF, but with higher density and toughness.
Basic Physical Properties:
| THE K11™ PEEK GF10 | Printed copy (horizontal printing of sample, 100% linear filling) | Injection molded parts | Test standards |
| Density (g/cm3) | 1.35 | ISO 1183 | |
| Melt index (g/10min) * 1 | 10-15 | ISO 1133 | |
| Thermal deformation temperature (℃) * 2 | 202 | ISO 75 | |
| Vicat softening temperature (℃) * 3 | / | ISO 306 | |
| Tensile strength (MPa) | 80-85 | ISO 527 | |
| Tensile elongation at break (%) | 6-8 | ||
| Bending strength (MPa) | 120-130 | ISO 178 | |
| Bending modulus (MPa) | 4000-5000 | ||
| Notched impact strength (KJ/m2) | 48-55 | ISO 179 | |
| Notch impact strength (KJ/m2) | 8-12 | ||
*1. Test condition: temperature (T)=380 ℃; Mass (m)=5kg.
*2. Test condition: bending stress=0.45MPa; Heating rate=120 ℃/h.
*3. Test condition: load=10N; Heating rate=120 ℃/h.
